All Categories > Safety Store > Basic Gate Switches > NZ1VZ Safety Gate Switch with Metal Housing > Item # NZ1VZ-2121E-M
Request Information

Item # NZ1VZ-2121E-M, NZ1VZ Safety Gate Switch with Metal Housing
Price $155.56



    border="0" Printable Page
    Email Email This Page
    Save To Favorites Save To Favorites




Euchner 089486 Safety gate switch with 4 N.C. positively driven contacts, 4 way entry head, category 2, anodized die-cast alloy body, M20 x 1.5 cable entry, IP67 rating..

NZ1VZ

larger image

NZ1VZ dimensions

larger image


 Specifications

Quantity in Stock

3

UPS Transit Time

 View 		If we are out of Stock, Click Here to Contact us

Manufacturer

Euchner

Type

Without Guard Locking

Actuation Style

Separate Actuator (See Suggested Accessories)

Safety Category

2

Contact Type

Slow action switching element

Contact Configuration1

4 N.C.

Connections

Screw Terminal (M20 x 1.5)

Dimensions (mm)

115Hx40Wx42D

Actuating Force

35 N

Max. Approach Speed

20m/min.

Rated Insulation Voltage

250VAC/DC

Contact Material

Silver alloy, gold flashed

Housing Material

Anodized die-cast alloy

Ambient Temperature Range

-25 to +80 ºC

Protection Standard

IP67

Miscellaneous Information

  • Horizontal approach direction (can be adjusted in 90° steps)
  • Mechanical life up to 2 million operating cycles

    • Suggested Accessories

    		016849, Actuators for NZ.VZ/TZ Safety Gate Switches ($15.53)
    024298, Actuators for NZ.VZ/TZ Safety Gate Switches ($53.41)
    MCG-M20, Metric Thread Nickel-plated Brass Cord Grips ($7.40)
    1 = Positively Driven

     MORE IMAGES

    · Wiring Diagram for 2131H

     DOWNLOADS

    width= Details for NZ Series
    (PDF, 94KB)

     Suggested Accessories for NZ/TZ


    Z-G

    016849
    Actuators for NZ.VZ/TZ Safety Gate Switches
    $15.53

    Metal Cord Grip

    MCG-M20
    Metric Thread Nickel-plated Brass Cord Grips
    $7.40

    more available ..

     Suggested Bolts for NZ


    NZ-A

    057734
    Bolt NZ-A
    $372.62

    NZ-A

    057735
    Bolt NZ-C
    $372.62

    more available ..
